Máy tính công nghiệp không quạt gắn tủ cabinet CMC 300-F13

Cabinet Mount Fanless PC with Intel® Xeon® E-2278GEL and 8/9th Gen Intel® Core™ i7/i5/i3 Processors

Tính năng chính

Fanless system design
Intel® Xeon® E-2278GEL and 8th & 9th Gen Intel® Core™ i7/i5/i3 LGA socket type processors
2 x Gigabit Ethernet
2 x USB 2.0, 2 x USB 3.0, 1 x COM RS232/422/485
IP65 protection on the outside heatsink
1 x DVI-D display output
2 x DDR4 up to 64GB
1 x mini-PCIe for storage device
2 x Easy-access 2.5” SSD trays
Support power input 24 VDC

Giá sản phẩm: Liên hệ

The CMC 300-F13 industrial fanless PC series has been designed with the purpose of being installed in the plate of the control cabinet or in the rear plate of a control cabinet. This fanless PC cut-in to a suitable cut-out in the control cabinet and its heatsink is at outside the cabinet with IP65 protection. The CMC 300-F13 is up to high performance Intel^® Xeon^® grade CPU with one PCIe x8 expansion and two external 2.5” HDD trays. This product meets easy maintenance condition in the industrial such as wind power, charging station.

* Thông tin đặt hàng

CMC 300-F13 (P/N: 10CM0030005X0)
one PCIe x8 expansion slot

Front I/O Interface Status LEDs	Power SATA (SSD)
Expansion	One PCIe x8 expansion slot from PCIe x8 Riser Card
Power	DC power input: -Input voltage: 18VDC -5% to 24VDC +10%, 7.5A -Reverse polarity protection
Environment	Operating temperature: - 0°C to 55°C with natural convection - 0°C to 60°C with mild forced airflow Operating humidity support 10%~90% relative humidity, noncondensing Vibration protection w/ HDD condition: - Random: 0.5Grms @ 5~500 Hz, IEC60068-2-64 - Sinusoidal: 0.5Grms @ 5~500 Hz, IEC60068-2-64
Certifications	CE (EN61000-6-2/EN61000-6-4) FCC Class A
I/O Ports	DC power input connector: 3-pin Phoenix contact terminal blocks COM: 1 x RS232/422/485 Display: 1 x DVI-D port Ethernet: 2 x RJ45 - LAN: 1 x Intel® I219-LM PHY LAN and 1 x Intel® I210-IT Gigabit LAN - Ethernet interface: 10/100/1000 Mbps - Support wake up on LAN 2 x USB 2.0 ports 2 x USB 3.0 ports 2-Pin remote power on/off 1 x Easy-access RTC battery socket
Physical Characteristics	Dimension: 330mm x 275mm x 116.2mm Weight: 6 KG Aluminum extrusion heat sink and iron nickel plating housing Back cover with reserved RAID card heatsink hole IP65 protection for the outside heatsink
Hãng

DATASHEETS

CMC300-F13 (1).pdf

[ CMC300-F13 (1).pdf , 0.6MB , Apr.11.2024 ]
