Industrial Gateway
- NXP i.MX8M Plus Cortex®-A53 quad core processor
- Embedded Neural Processing Unit (NPU) delivers up to 2.3 TOPS AI performance
- 1 x HDMI
- 1 x USB 3.0, 1 x USB 2.0
- 1 x COM
- 2 x GbE LAN ports
- 1 x Full-size mini-PCIe for optional Wi-Fi/BT/4G LTE (PCIe 3.0, USB 2.0, SIM)
- 1 x Internal M.2 2230 Key E (USB 2.0, SDIO, UART)
- Modular rear I/O design for easy customization
- Support 9~30V DC input
- TI Sitara™ AM3352 Cortex®-A8 800MHz processor
- 1GB of DDR3-800 and 8 GB of eMMC NAND Flash onboard
- 2 Gigabit Ethernet ports
- 2 RS232/485, 1 USB OTG, 6 GPIO
- WiFi/BT/LTE solution ready
- Yocto Linux support
- -20 ~ 70 °C operating temperature/ 12~24V DC power supply
- Equipped with hardware watchdog timer for system protection
- Onboard Intel® Atom™ processor E3826 dual core, 1.46GHz
- 1 x HDMI Display
- 2 x Intel® I210AT GbE LAN ports; Support WoL, Teaming and PXE
- 4 x USB 2.0
- 3 x mini-PCIe sockets for optional Wi-Fi/3.5G/LTE modules
- 1 x RS232, 1 x RS232 (only Tx/Rx/GND), 1 x RS422/485 with auto flow control
- Support -10°C to 60°C operating temperature
- Support 24V DC input
- Onboard Intel® Celeron® processor J3455 Quad Core, 1.50GHz
- 3 x HDMI
- 6 x USB 3.0, 2 x USB 2.0
- 1 x RS232/422/485, 3 x RS232
- 3 x Intel® I210 GbE LAN ports; support WoL, teaming and PXE
- Onboard TPM 2.0 chip
- 2 x mini-PCIe socket support optional mSATA/Wi-Fi/BT/4G LTE module
- Support operating temperature from -10°C to 60°C
- Support +9V to 30VDC input; support ATX power mode
- Onboard Intel® Celeron® processor J6413 Quad Core 1.8GHz
- 1 x DP++ and 1 x HDMI for dual independent display support
- 1 x Intel® 2,5GbE LAN port, support WoL & PXE
- 2 x Marvell PHY GbE LAN ports, support WoL
- 2 x RS232/422/485 with auto-flow control and 2.5KV isolation protection
- 2 x USB 3.0, 4 x USB 2.0
- 1 x Front access 2.5” SATA HDD/SSD tray, support ComboStorage (2.5” SSD + MicroSD card)
- 2 x mini-PCIe socket support optional modules and mSATA device
- 1 x M.2 3042/3052 Key B socket
- TPM 2.0 onboard
- PCIe x4 expansion
- Support +24VDC input, support ATX power mode
Extremely compact design with a fanless cooling system
The EACIM20 industrial IoT gateway has a compact design of 100 x 70 x 31 mm (one layer, without mounting bracket) made of metal housing to withstand industrial challenges. Its fanless design offers an optimized thermal solution for a reliable and long-lasting industrial technology. Deliver reliable operation in limited space, poor ventilation, dust-prone, and corrosive conditions.
Enable Seamless Edge to Cloud Integration
Winmate’s EACIM20 industrial IoT gateway platform features a secure, seamless edge-to-cloud connection, and scalable computing performance based on an A53 Quad-core processor.
Comprehensive connectivity
EACIM20 gateway supports superior connectivity enabling seamless interconnection, ensuring interoperability between systems, enabling seamless edge-to-cloud connection, data aggregation, filtering, and data transmission. Easily collect data from a swarm of edge devices through a comprehensive I/O set and transmit it to the cloud over wireless communications.
Easy Mounting
EACIM20 IoT gateway offers easy installation and deployment with various mounting options such as desk, wall, VESA, or Din-Rail.
* Thông tin đặt hàng
Option
- EACIM20-100 Standard SKU
- EACIM20-101 with WLAN and BT SKU (Optional)
- EACIM20-102 with WWAN SKU (Optional)
- EACIM20-103 with WLAN, BT and WWAN SKU (Optional)
- EACWSLT-231 3-port RS232/422/485 w/ isolation (Optional)
- EACWSLT-232 16-Channel Digital I/O w/ isolation (Optional)
- EACWSLT-233 2-port CANBUS w/ isolation (Optional)
- EACWSLT-234 4-port USB 2.0 (Optional)
- EACWSLT-235 2-port RS232/422/485 w/ isolation (Optional)
- Onboard Intel® Celeron® processor J1900 Quad Core, 2.42GHz
- 1 x HDMI display
- 3 x Intel® I210-IT GbE LAN ports; support WoL, teaming and PXE
- 2 x USB 2.0
- 1 x mini-PCIe socket for optional Wi-Fi/BT modules
- 1 x mini-PCIe socket for optional mSATA storage
- 1 x RJ45 COM serial port for RS232 signal
- Support -10°C to 60°C operating temperature
- Support 12V DC input
