1 x SO-DIMM socket supprt up to 8GB DDR3L 1600 MHz, non-ECC and un-buffered memory

1 x M.2 Key M 2242 SSD (SATA 3.0)

2 x Antenna hole

• LED for power on/off
• Power switch12V DC-in power Jack lock type
• 2 x RJ45 with LEDs for Gigabit LAN
• 1 x HDMI2.0, resolution 4096 x 2160 60Hz
• 2 x USB 3.0
• 1 x Line-out
• COM 1: RS232/422/485

• LCD size: AUO G-series 10.1”, 16:10
• Resolution: WXGA 1280 x 800
• Luminance

- LCD panel: 400cd/m2
- XPPC PCAP touch: 90% of panel’s luminance after optical bonding

• Contrast ratio: 800
• LCD color: 16.7M
• Viewing angle: 89 (U), 89 (D), 89 (L), 89 (R)
• Backlight: LED
• Touch Screen: 10-point PCAP (projected capacitive touch)
• Optical bonding: Glass surface treatment: AS (Anti-Smudge Coating for easy cleaning)

• 1 x mini-PCIe full-size connector with SIM slot (full-size) onboard, support Wi-Fi/LTE module

• 1 x 60W AC/DC lockable adapter included in accessory
• Input: 100VAC to 240VAC
• Output: DC 12V

• Vibration

- IEC 60068-2-64
- 2Grms@sine, 5~500Hz, 1hr/axis
- 2.2Grms@random condition, 5~500Hz, 0.5hr/axis (non-operating)

• Shock

- IEC 60068-2-27
- 20g peak acceleration (11msec. duration)

• Temperature

- Operating temperature with 0.7 m/s air flow: 0°C~50°C
- Storage temperature: -20°C~60°C

• Operating humidity: 10%~90% relative humidity, non-condensing limits to be at 90%

• CE (EN55035 + EN55032)
• FCC Class A (EMI part 15B)
• LVD (EN62368-1)

• Color/material: black, silver/metal sheet
• Support

- VESA mount 75mm x 75mm
- Panel mount
- Open frame

• System: 260.3mm x 178.3mm x 44.65mm
• System weight: 2 kg
• Package: 335mm x 302mm x 160mm
• Package weight: 3 kg

• Windows 10, 64-bit
• Linux
