• 2 x 262-pin 4800MT/s dual-channel DDR5 SO-DIMM slots (system max. 64GB)

• 2 x M.2 2280 M key (PCIe/ SATA) with RAID

• Size: 21.5”
• LCD Resolution: 1920 x 1080
• LCD Brightness (cd/m²): 350
• LCD Contrast Ratio: 1000:1
• LCD Color: 16.7M (RGB 8-bit)
• LCD Pixel Pitch (mm): 0.2745 (H) x 0.2745 (V)
• LCD Viewing Angle (H-V): 178°/178°
• LCD Backlight MTBF: 50000
• Touch Screen: PCAP
• Touch Controller: EETI
• Touch Surface Hardness: 6H
• Touchscreen Coating: Chemical etching AG

• 1 x PCIe x2
• 1 x M.2 2230 A-E key (PCIe+USB)
• 2 x M.2 2260/80 B-M key (PCIe/ SATA)

• Input: 85V – 264V AC input
• Built-in Power Supply: 150W, 85V – 264V AC, medical power supply

• Operating Temperature: 0°C ~ 40°C
• Storage Temperature: -20°C ~ 60°C
• Humidity: 10% ~ 90% (non-condensing)
• Vibration: 1G
• Operating Shock: 5G peak acceleration (11ms duration)
• Non-operating shock: 15G peak acceleration (11ms duration)
• IP LevelFront: IP66

• Safety & EMC
• CE, FCC Class B Part18, UL 60601-1, IEC/EN 60601-1, IEC/EN 60601-1-2

Buttons

• 1 x Power on/off
• 1 x AT/ATX switch
• 1 x Reset button
• 1 x Clear CMOS Button

Indicators

• 1 x Power indicator

Other Features

OSD Function

• 1 x Power on/off
• 1 x Reading light on/off
• 1 x Brightness up
• 1 x Brightness down
• 1 x LCD & touch lock on/off
• 1 x DICOM mode app on/off (optional)

• Thermal: Fanless
• Construction Material: ABS+PC plastic
• Mounting: Wall, Stand and Arm; VESA 75/100 compliant
• Weight (Net) (kg): 6.9kg
• Dimensions (LxWxH) (mm): 507.5 x 335.5 x 64.5
