Climate

• EN 50155, class OT4 Railway applications - Electronic equipment used on rolling stock EMC
• EN 50155, Railway applications - Electronic equipment used on rolling stock
• EN 50121-3-2, Railway applications – Electromagnetic compatibility, Part 3-2: Rolling stock – Apparatus
• ETSI EN 301 489-1, Electromagnetic compatibility (EMC) and Radio spectrum Matters (ERM) for radio equipment and services - Part 1: Common technical requirements
• ETSI EN 301 489-17, Electromagnetic compatibility (EMC) and Radio spectrum Matters (ERM) for radio equipment - Part 17: Specific conditions for Broadband Data Transmission Systems Mechanical (Shock and vibration)
• EN 61373, category 1, class B Insulation (Coordination and test)
• EN 50155, Railway applications - Electronic equipment used on rolling stock Radio communication
• ETSI EN 300 328, Wideband transmission systems; Data transmission equipment operating in the 2.4 GHz ISM band and using wide band modulation techniques
• ETSI EN 301 893, 5 GHz RLAN
• ETSI EN 300 440, 5.8GHz, Short Range Devices
• IEEE802.11, Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications Safety
• EN/IEC 61010-1, Safety requirements for electrical equipment for measurement, control, and laboratory use
• EN 45545-2, Fire protection on railway vehicles

• Operating temperature: -40 to +70°C (-40 to +158°F)
• Ingress protection: IP66

• Rated voltagea. 24 to 110 VDC or IEEE 802.3 PoE Class 4
• Rated power: 14W PoE
• PoE: Class 4 (IEEE 802.3at type 1 and 2 PD)

Security

• WPA2-Personal (CCMP), WPA2-Enterprise, WPA3-Personal (SAE/OWE), WPA3-Enterprise (Suite-B), 802.11w, 802.1X, SecureBoot (TPM), Security Log (persistent)

Networking

• Fixed fallback IP, IP Aliases, MAC override, VLAN support, Interface Port Protection, Routing Static/ Policy/Multicast, Multi WAN support, CARP, DHCP Server/Client/Relay, DNS Server/Client, NTP Server/Client, RSTP, Firewall Filter/Mangle (L2 stateless/L3 stateful), IP Masquerading (NAT/NAPT), Port Forwarding (DNAT/SNAT), Stateless NAT (1-1 NAT)

Wireless

• 802.11r, 4addr, QoS (L2/L3 mapping), Access Control (ACL), Automated Channel Selection (ACS), AP Client Isolation, SSID Hide, BSSID override

VPN

• SSL Server/Client, IPsec, OpenVPN Client, Wireguard, GRE/GRETAP, VXLAN

Discovery

• LLDP, SSDP, mDNS

Client management

• ATF (Air Time Fairness), Client Steering and Load Balancing between 2.4 GHz and 5 GHz, Multi-AP Client Steering, 802.11k, 802.11v

Monitoring

• Built-in monitoring sensors and diagnostics, SNMP notifications (TRAP/INFO), Syslog, CLI

Management

• SNMP v2c/v3 with USM authentication and encryption support, HTTP/HTTPS web interface and WebAPI with user authentication (local or LDAP), CLI (SSH and Telnet), Certificate Management (SCEP), Dual Firmware Primary/Backup

SNMP MIB Support

• MIB-2, RFC1213, HOST-RESOURCES, BRIDGE, ETHERLIKE, IF-MIB, LLDP-MIB, UCD-SNMPMIB, WESTERMO-SW6-MIB, WESTERMO-SW6-BRIDGE-MIB, WESTERMO-SW6-FIREWALL-MIB, WESTERMO-SW6-ICL-MIB, WESTERMO-SW6-NWM-MIB, WESTERMO-SW6-PWN-MIB

• Operating modes: Access Point, Client, Bridge
• Interfaces: Dual-Band Concurrent 2x2 MU-MIMO (total 4 Spatial Streams)
• Standards supported: IEEE 802.11g, 802.11a, 802.11n, 802.11ac, 802.11ax
• Frequency range: 2.400 to 2.4835 GHz (2x2 MU-MIMO) 5.150 to 5.350 GHz, 5.470 to 5.725 GHz, 5.725 to 5.875 GHz (2x2 MU-MIMO)
• Data rates supported: 2.4 GHz: Up to 802.11ax 40 MHz 2SS BW HE11: 573 MBit/s 5 GHz: Up to 802.11ax 80 MHz 2SS BW HE11: 1201 MBit/s
• RF transmit power 2.4 GHza. Max. conducted transmit power: 25 dBm, per port: 22 dBm
• RF transmit power 5 GHza. Max. conducted transmit power: 25 dBm, per port: 22 dBm
• Receiver sensitivity per radiob. 20 MHz: -94 dBm (HE0), -68 dBm (HE9), -63 dBm (HE11) 40 MHz: -91 dBm (HE0), -65 dBm (HE9), -61 dBm (HE11) 80 MHz: -88 dBm (HE0), -63 dBm (HE9), -58 dBm (HE11)

• Dimensions (W x H x D): 195 x 70 x 111 mm (7.68 x 2.76 x 4.37 inches)
• Housing: Full metal
• Weight: 1.45 kg without antennas
