• 1 x DDR5 4800 SO-DIMM, default 8GB

• 2 x 2.5” SATA 3.0 HDD/SSD tray, removable, 15mm
• 1 x 64GB eMMC default for OS

• 10 x LED indicator (including 1 x programmable LED)
• 4 x Externally accessible nano-SIM card socket with cover
• 2 x 2.5” removable SSD tray, removable, 15mm
• 1 x Reset button
• 1 x Power button
• 2 x USB 3.2 Gen 2, Type-A
• 1 x HDMI® 2.0
• 1 x Mic in, 1 x Line out, 1 x Line in
• 5 x SMA antenna

• 1 x 3-pin terminal block for 9V~48V DC
• 4 x 2.5GbE RJ45 PoE port, Intel® I226-IT (2 x 802.3 bt + 2 x 802.3 af/at), total up to 90W (PoE++1, PoE++2, PoE+3, PoE+4)
• 1 x 2.5GbE RJ45 port, I226-IT
• 1 x VGA, up to 1920 x 1200@60Hz
• 2 x COM port (DB9), supports RS-232/422/485
• 4 x SMA antenna
• 2 x USB 2.0 Type-A
• 1 x DB15 (Multi1 Port)

- 4 x DI with isolation
- 4 x DO with isolation
- 1 x GNSS Speed/Direction
- Vin, GND for GPIO

1 x DB15 (Multi2 Port)
- 1 x RS-422/485
- 1 x RS-232 (TX/RX)
- 1 x CAN FD
- 1 x 12V DC, 2A output (Vout, GND)

1 x Mini PCIe slot (PCIe 3.0, USB 2.0), BOM optional M.2 3052 Key B (USB 3.2, USB 2.0)
- Support LTE/5G NR module with 2 x external SIM1 x M.2 3042/3052 Key B (USB 3.2, USB 2.0)
- Support LTE/5G module1 x M.2 2230 Key E (PCIe 3.0, USB 2.0), BOM optional mPCIe (PCIe 3.0, USB 2.0)
- Support Hailo module

• 1 x U-blox NEO-M9N GNSS for GPS/Glonass/QZSS/Galileo/Beidou
• 3D accelerometer and 3D gyroscope

• 4 x 2.5GbE RJ45 PoE port, Intel® I226-IT (2 x 802.3 bt + 2 x 802.3 af/at), total up to 90W (PoE++1, PoE++2, PoE+3, PoE+4)
• 1 x 2.5GbE RJ45 port, I226-IT

• TPM 2.0, Infineon SLB9672VU2.0

• Power input 9~48 V DC
• Selectable boot-up & shut-down voltage for low power protection by software
• Setting the 8-level power on/off delay time by software
• Support S3/S4 suspend mode
• 10~255 seconds WDT support, set up by softwareSDK (Windows/Linux), including utility and sample code

• Operating temperatures: -40°C to 70°C (w/ industrial SSD) with air flow
• Storage temperatures: -40°C to 85°C
• Relative humidity: 10% to 90% (non-condensing)
• Vibration (random)

- 2g@5~500Hz (in operation, SSD)

Vibration (SSD)
- Operating: MIL-STD-810H, Method 514.8C Procedure 1, Category 4, common carrier US highway truck vibration exposure
- Storage: MIL-STD-810H, Method 514.8E Procedure 1, Category 24, minimum integrity test

Shock (SSD)
- Operating: MIL-STD-810H, Method 516.8, Procedure I, functional shock=40g
- Non-operating: MIL-STD-810H, Method 516.8, Procedure V, crash hazard shock test=75g

• CE
• FCC Class A
• E13 mark

• Dimensions: 260mm (W) x 196mm (D) x 66.5mm (H)
• Weight: 3.2kg

• Windows 10 64bit, 11
• Linux 4.x
