• 1 x 262-pin DDR5 SO-DIMM socket support 4800MHz up to 16GB, default 8GB

• 1 x 2.5” SATA 3.0 external SSD (compatible with 15mm drive)
• 1 x mSATA (occupy one mPCIe slot)

• 12 x LED indicators (including 2 x programmable LED)
• 8 x Externally accessible SIM card sockets with cover
• 1 x 2.5" removable SSD tray (removable, 15mm)
• 1 x Reset button
• 1 x Power button
• 2 x USB 3.2 (Gen 2) type A
• 14 x SMA antenna

• 1 x Circle type DC input with ignition

- 24 VDC (9~36 VDC), non-isolation

• 1 x M12 with two USB 2.0
• 2 x M12 X-coded LAN port, 10/100/1000/2500 Mbps
• 1 x DB9 (AUDIO), female for 1 x Mic-in, 1 x Line-out, 1 x Line-In
• 1 x VGA, 1 x HDMI 2.0, 1 x DP
• 1 x DB9 (COM) full RS232 (isolation)
• 2 x DB9 for RS232/RS422/RS485 Full (all w/ isolation)
• 1 x 18-pin terminal block

- 1 x CAN FD
- 4 x DI with isolation
- 4 x DO with isolation
- 1 x GNSS Speed/Direction
- Vin, GND for GPIO

• 2 x M.2 3042/3050/3052 Key B socket (USB 2.0, USB 3.2 Gen 2) for LTE/5G NR module with 2 x external Nano-SIM
• 1 x Full size mini-PCIe socket (USB 2.0, SATA, PCIe 3.0) for mSATA (default), BIOS select (USB 2.0) for LTE with 2 x external Nano-SIM, BOM option (USB 2.0, PCIe 3.0) for WLAN
• 1 x M.2 2230 Key E (PCIe 3.0 x 1, USB 2.0), BOM optional mPCIe (PCIe 3.0 x 1, USB2.0) for Hailo module
• 1 x Full size mini-PCIe socket (USB 2.0, PCIe 3.0) for WiFi, BOM option M.2 3042/3050/3052 Key B socket (USB 2.0, USB 3.2 Gen 2) for LTE/5G NR module with 2 x external Nano-SIM

• 1 x Default u-blox NEO-M9N GNSS for GPS/Glonass/QZSS/Galileo/ Beidou
• G Sensor (3-axis, 10-bit resolution)

• 2-Port LAN, 10/100/1000/2500 Mbps I226-IT Ethernet Controller

• TPM 2.0: Infineon SLB9670VQ2.0

• Power input 24 VDC w/o isolation
• Selectable boot-up & shut-down voltage for low power protection by software
• Setting 8-level power on/off delay time by software
• Support S3/S4 suspend mode
• 10~255 seconds WDT support, setup by software
• SDK (Windows/Linux) including utility and sample code

• Operating temperatures

- EN 50155, class OT4 (-40~70°C), 85°C for 10 minutes (w/ industrial SSD) with air flow

• Storage temperatures: -40°C to 85°C
• Relative humidity: 10% to 90% (non-condensing)
• Vibration (random)

- 2g@5~500 Hz (in operation, SSD)

• Vibration

- IEC 60068-2-64, 2G for SSD
- Operating: MIL-STD-810H, 514.8C Procedure 1, Category 4
- Storage: MIL-STD-810H, 514.8E Procedure 1, Category 24

• Shock

- Operating: MIL-STD-810H, Method 516.8, Procedure I, functional shock=40g
- Non-operating: MIL-STD-810H, Method 516.8, Procedure V, crash hazard shock test=75g

• CE
• FCC Class A
• EN 50155: 2017

- Ambient temperature EN 50155, Class OT4 (-40~70°C), 85°C for 10 minutes
- Interruptions of voltage supply class S1
- Supply change over class C1, C2
- EMC EN 50121-3-2: 2016+A1: 2019
- Environment EN 60068-2-1, EN 60068-2-2, EN 60068-2-30
- Shock and vibration IEC 61373 Class B
- Protective coating class PC1 (PC2, by request)
- EN 45545-2:2013+A1:2015 (PCB)

• Dimensions: 260mm (W) x 196mm (D) x 70mm (H) (10.24" x 7.79" x 2.75")
• Weight: 2.8kg

• 1 x VGA up to 1920 x 1200 @60Hz
• 1 x HDMI 2.0 up to 4096 x 2160 @60Hz
• 1 x DP up to 4096 x 2160 @60Hz

• Windows 10, 11 (64-bit)
• Linux 4.x

• nROK 6231-A (P/N: 10A00623100X0)

Intel Atom® processor x7433RE CPU, 8GB DDR5 SO-DIMM, DC input 24 VDC w/o isolation, 1 x VGA, 1 x HDMI, 1 x DP, 2 x LAN, 2 x selectable RS232/422/485 Full, 1 x RS232 Full, 8 x GPIO, 2 x USB 3.2, 2 x USB 2.0

• nROK 6231-AI (P/N: 10A00623101X0)

Intel Atom® processor x7433RE CPU, 8GB DDR5 SO-DIMM, DC input 24 VDC w/ isolation, 1 x VGA, 1 x HDMI, 1 x DP, 2 x LAN, 2 x selectable RS232/422/485 Full, 1 x RS232 Full, 8 x GPIO, 2 x USB 3.2, 2 x USB 2.0

• nROK 6231-FI (P/N: 10A00623102X0)

Intel Atom® processor x7433RE CPU, 8GB DDR5 SO-DIMM, DC input 110 VDC w/ isolation, 1 x VGA, 1 x HDMI, 1 x DP, 2 x LAN, 2 x selectable RS232/422/485 Full, 1 x RS232 Full, 8 x GPIO, 2 x USB 3.2, 2 x USB 2.0
