Màn hình công nghiệp APPD 1700-2

17” IP65 Industrial 4:3 SXGA LCD Flush Touch Monitor

Tính năng chính

  • IP65 compliant aluminum front bezel with flush panel by 5-wire touchscreen
  • Triple display input interface: analog VGA/DVI-D/DisplayPort
  • Shares identical appearance with the APPC series
  • Dual touch screen interface: RS-232 or USB (optional)
  • Ultra slim in depth
  • Multiple mounting ways for easy integration

Giá sản phẩm: Liên hệ

Lượt xem 19

The 17-inch 4:3 LCD display APPD 1700-2 features a 5-wire resistive touch screen, 400 cd/m2 brightness, and supports resolutions up to 1280 x 1024. APPD 1700-2 is ideal for space-constrained environments where systems and displays are separated. Its flush panel design with a slim bezel and IP65-rated front panel ensures durability in demanding industrial settings.



APPD 1700-2 offers a variety of video interfaces, including VGA, DVI, and DisplayPort, supporting both digital and analog signals. The touch screen can be connected using RS-232 or USB ports. APPD 1700-2 accepts 24VDC ±20% power input and provides panel mount and VESA mount options for flexible installation. APPD 1700-2 is the perfect companion for NEXCOM NISE fanless computers, NIFE Automation PC series, and APPC panel PCs when a second display is needed.

Rear I/O Interface
  • Touch screen interface port: RS-232 (1 x DB9) / USB Type-A
  • Video port: VGA (1 x DB15) / DVI-D (1 x DVI-I connector) / DisplayPort
  • DC power input connector: 3-pin Phoenix terminal block
Display

Panel

  • LCD size: 17”, 4:3
  • Resolution: SXGA 1280 x 1024
  • Luminance: 400cd/m²
  • Contrast ratio: 1000:1
  • LCD Color: 16.7M
  • Viewing angle: 80 (U), 80 (D), 85 (L), 85 (R)
  • Backlight: LED

Touch Screen

  • 5-wire resistive (flush panel type)
  • Light transmission: 78%
  • Interface: USB
Certifications
  • CE approval (EN 55032, EN 55035)
  • FCC Class A
Physical Characteristics
  • Color: Pantone 400C/RAL 090 80 10 aluminum front bezel and black silver chassis box
  • IP protection: IP65 front
  • Mounting: panel/wall/stand/VESA 100mm x 100mm
  • Power

- Power input: 24V DC ± 20%
- Power adapter: optional AC/DC power adapter (24V DC, 60W)

  • Vibration:

- 2G@sine, 5~500Hz, 1hr/axis (operating), IEC60068-2-64
- 2Grms@random condition, 5~500Hz, 0.5hr/axis (operating), IEC 60068-2-64

  • Shock:

- 20G@wall mount, half sine, 11ms (operating), IEC 60068-2-27

  • Temperature:

- Operating temperature: 0°C to 50 °C (Ambient with air flow)
- Storage temperature: -20°C to 75°C

  • Operating humidity: 10% to 90%, non-condensing (limits to beat 90% RH at max 50°C)
  • Dimension: 391.8mm x 325.6mm x 56.65mm
  • Weight: 4.5Kg
IP Rating IP65
Size 17"
Hãng NEXCOM

DATASHEETS
APPD1700-2.pdf
[ APPD1700-2.pdf , 0.4MB , Jul.02.2025 ]
