LEC-2430

Compact High-performance IPC Powered by the Intel® Bay Trail CPU

Tính năng chính

  • Intel® Celeron® J1900 processor
  • Fanless design
  • 2 Giga LAN ports
  • 2 serial COM ports
  • 5 USB ports
  • Mini-PCIe, PCI and PCI-E riser cards
  • 9VDC to 30VDC power input

Giá sản phẩm: Liên hệ

Lượt xem 77

The LEC-2430 is a cost-effective, energy-conscious and powerful embedded appliance. Its fanless, robust and compact design simplify deployments and maintenance at locations with limited and confined spaces. Its Intel® Celeron® J1900/N2930 or Intel® Atom™ E3845 processor offers much improved graphical/media performance while its mini-PCIe, PCI and PCI-E riser cards offer expansion capability and extended funtionalities.



Environment
  • Storage temperature: -20°C to 70°C
  • Operating temperature: 0°C to 55°C
  • Operating humidity: 5% to 95% (non-condensing)
Certifications
  • CE/FCC, Class A
I/O Ports
  • Graphic controller: Intel HD Graphics
  • Audio controller: Realtek ALC886
  • Max LAN: 2 x RJ45
  • Display output: 1 x VGA, 1600 x 1200, 1 x HDMI, 1920 x 1080
  • Audio ports: 2 x Phone Jack for MIC-in and Line-out
  • Serial ports: 2 x RS-232/422/485, DB9 male
  • USB 2.0: 4 x Type A
  • USB 3.01 x Type A
  • Expansion: 1 x full-sized socket with SIM card reader,1 (default) PCI, 1 (accessorary package) PCI Express x1
  • Reset: 1 x power on/off, and 1 x reset
Ethernet controller
  • Ethernet controller: Intel i210
Physical Characteristics
  • Dimensions (W x H x D): 268 mm x 65.5 mm x 195 mm (10.55" x 2.58" x 7.68")
  • Weight: 2.7 kg (5.94 lbs)
  • Watchdog: Watchdog timer 256 level time interval system reset, software programmable
  • Casing material: Aluminum + SGCC

DATASHEETS
LEC-2430_DM-v1.2020.0430.pdf
[ LEC-2430_DM-v1.2020.0430.pdf , 1.21MB , Mar.06.2024 ]
Resource
LEC-2430_manual_v1.2.pdf
[ LEC-2430_manual_v1.2.pdf , 0MB , Mar.06.2024 ]
