EPC-R3220
Tính năng chính
- TI Sitara™ AM3352 Cortex®-A8 800MHz processor
- 1GB of DDR3-800 and 8 GB of eMMC NAND Flash onboard
- 2 Gigabit Ethernet ports
- 2 RS232/485, 1 USB OTG, 6 GPIO
- WiFi/BT/LTE solution ready
- Yocto Linux support
- -20 ~ 70 °C operating temperature/ 12~24V DC power supply
- Equipped with hardware watchdog timer for system protection
Giá sản phẩm: Liên hệ
EPC-R3220 is a RISC-based box computer integrated with the TI Sitara AM3352 Cortex-A8 0.8GHz processor. It is designed for applications that require multiple connectivity points and low power consumption. The EPC-R3220 offers dual RS-232/485 serial ports with Modbus/OPC-UA protocol support for date collection, 6GPIOs for indication or device control, dual 10/100/1000 Ethernet ports, one wifi/BT onboard solution and one Mini-PCIE that can expand to an LTE solution. EPC-R3220 supports wide-ranging power input and temperature and supports both DIN-rail and wall mounting.
| Expansion |
|
| Power |
|
| Environment |
|
| Certifications |
|
| I/O Ports |
|
| Physical Characteristics |
|
| Specifications |
- Transceiver: RTL 8211 - Speed: 2 x 10/100/1000 Mbps
- WIFI/BT: IEEE 802.11ac/a/b/g/n 2*2 WLAN+BT 4.2 On board (option) - WatchDog Timer: MSP430G2202 (timeout: 1 ~ 6553s, default 60s/power on/off 1s) |
| Hãng | ADVANTECH |
