IPC-6608BP-00D

8-Slot Desktop/Wallmount Chassis with PS/2 or Redundant Power Supply

Tính năng chính

  • Bidirectional options to mount the chassis on the wall or workbench
  • Supports versatile 6/8-slot backplanes to hold 6/8 full-size cards
  • One/two front-accessible 5.25" disk drives and one 3.5" FDD
  • High-speed cooling fan supports abundant cooling and streamlined ventilation
  • Shockproof and anti-vibration drive bay design for industrial applications
  • Two front-accessible USB ports

Giá sản phẩm: Liên hệ

Lượt xem 8

I/O Interface (Front)

USB 2.0

  • 10 D-sub openings supporting up to 10 COMs with optinal COM cables
Form Factor
  • PICMG 1.0/1.3
Disk Drive Bay
  • 2x 5.25"
  • 2x External 3.5"
Cooling
  • System Fan: 1 (12 cm , 82 CFM)
  • Air Filter: Yes

Miscellaneous
  • LED Indicators: Power, HDD
  • Control: Power Switch, System reset

Physical Characteristics
  • Weight: 11 kg ( 24.2 lb)
  • Dimensions (W x H x D): 173 x 315 x 410 mm ( 6.8" x 12.4" x 16.1" )

DATASHEETS
IPC-6606_6608_DS(070720)20200710150324.pdf
[ IPC-6606_6608_DS(070720)20200710150324.pdf , 1.2MB , Mar.09.2024 ]
